1. Full pure diode RGB laser with more stable performance and longer working life.The machine can work in -20°C- 50°C.
2. Three floors designs, more compacted and much lighter.
1) Top floor: Optical and electric components. Dust proof designs, no maintenance costs. Electric components on the top floor, easy to install and replace. The heat is transmitted to the heat sink.
2) Middle floor: Heat sink floor. The high speed fans will blow away the heat and keep the machine in good working temperature.
3) Bottom floor: Power supply components.
3. Made of analog laser modulation. Users can dimmer the laser brightness linearly to makes the laser light more colorful.
4. There are some optional control hardware for your choice.
1)Built in FB4. It can export programs from Quickshow software that no need to link the computer with the laser during the operation.
Also users can link the laser light projector with computer software by RJ45 internet cable which is easy to get in the market.
Quickshow is one of the popular laser control software in the market.There are about 2000 cues built inside.Users can edit the text,setting the display time code,draw their own programs in the software easily and the laser can show them out at the same time.
2)Built in Showtower. It is Chinese hardware which is using Truwave software.It can export cues to the hardware and run in auto mode.
Also can be control via Artnet or DMX.There are also lots of cues and graphics for your choice.You can make your own one too.
|Guaranteed Power||20 watt|
|Red Laser Power||6 watt|
|Green Laser Power||6 watt|
|Blue Laser Power||10 watt|
|Beam Specification||ca.: <7mm, divergence: <1.1mrad|
|Scanner||LY2309(35KPPS@8°) or DT50BB(35KPPS@8°)(optional)|
|Max Scanning Angle||60°|
|Patterns Built Inside||More than 128 kinds of beam and graphics|
|Play Mode||Auto,Sound Active,DMX,Master/Slave,ILDA,TF card|
|Input Voltage||AC 100~250V,50/60HZ|
